Product details of DC Fan/Motor Speed Controller Module 1.5V-35V 5A 90W Speed Regulator
Supply Voltage: DC 4.5V-35V 5A
Control power: 90W (max)
Size: 30 x 26 x 14 mm (Without Handle)
PWM duty cycle: 1% -100%
PWM frequency: 10khz
This Module is often to control the speed of any DC motor which is functioning at 1.5-35v and current is lower to 5A.
DC Air Cooler
DC Pedestal Fan
DC Lights
This Circuit Will Only Work With those Motor’s which is directly connected to the present module. if the motor already connected with another negative feedback circuit or kit, please detach the motor from that circuit for correct operation.
DC Motor Speed Controller input is DC, can’t directly be connected to the AC (for example home 220V AC), otherwise, it’ll burn.
DC power supply positive and negative terminals don’t reverse, otherwise the DC motor Speed Controller could also be damaged.
The motor is often positive or negative, when the direction of operation and expectations don’t match, you’ll adjust the road order to vary the direction.
Adjust the potentiometer knob to vary the Speed Controller output duty cycle, the motor speed changes.
The shapes of the module sent to you might a bit different.
Supply Voltage: DC 4.5V-35V 5A
Control power: 90W (max)
Size: 30 x 26 x 14 mm (Without Handle)
PWM duty cycle: 1% -100%
PWM frequency: 10khz
This Module is often to control the speed of any DC motor which is functioning at 1.5-35v and current is lower to 5A.
The Major uses of this circuit are:
DC Air Cooler
DC Pedestal Fan
DC Lights
Note:
This Circuit Will Only Work With those Motor’s which is directly connected to the present module. if the motor already connected with another negative feedback circuit or kit, please detach the motor from that circuit for correct operation.
DC Motor Speed Controller input is DC, can’t directly be connected to the AC (for example home 220V AC), otherwise, it’ll burn.
DC power supply positive and negative terminals don’t reverse, otherwise the DC motor Speed Controller could also be damaged.
The motor is often positive or negative, when the direction of operation and expectations don’t match, you’ll adjust the road order to vary the direction.
Adjust the potentiometer knob to vary the Speed Controller output duty cycle, the motor speed changes.
The shapes of the module sent to you might a bit different.
